This is the complete Maruti Suzuki Ertiga wiper blade size guide: verified sizes for every generation and model year, the variants each size fits, and how to replace the blades yourself in a couple of minutes.
Maruti Suzuki Ertiga wiper blade size – quick answer
- Maruti Suzuki Ertiga (2012–present): 22" + 14" (550 mm + 350 mm)
All sizes fit the standard U-hook (J-hook) wiper arm.
Maruti Suzuki Ertiga wiper blade size by generation
| Generation | Years | Driver side | Passenger side | |
|---|---|---|---|---|
| Gen 1 (incl. 2015 facelift) | 2012–2018 | 22" (550 mm) | 14" (350 mm) | Shop |
| Gen 2 | 2018–2022 | 22" (550 mm) | 14" (350 mm) | Shop |
| Gen 2 facelift | 2022–present | 22" (550 mm) | 14" (350 mm) | Shop |
Find your model year
- 22" + 14" – Ertiga: 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Variants covered
Wiper size depends on the windscreen, not the trim, engine or fuel – every variant of a generation takes the same blades:
- Ertiga: LXi, VXi, ZXi, ZXi+, LDi, VDi, ZDi, Tour, CNG
How to replace Ertiga wiper blades
- Lift the wiper arm away from the windscreen until it locks upright.
- Press the release tab on the U-hook adapter and slide the old blade down off the hook.
- Slide the new blade onto the hook until it clicks into place.
- Lower the arm gently and repeat on the other side with the correct length.
- Test with washer fluid – the glass should be clear in one sweep.
When to replace
Every 6–12 months, or sooner if the blades streak, squeak, judder or leave unwiped patches – especially before the monsoon.
Buy Ertiga wiper blades
Prootto sells exact-fit sets of two in Conventional, Hybrid, Frameless and Carbon Aero:
FAQs
What is the wiper blade size of the Maruti Suzuki Ertiga?
Ertiga (2012–present): 22" + 14" (550 mm + 350 mm).
Is the wiper size the same for every Ertiga variant?
Yes. Within a generation, LXi, VXi, ZXi, ZXi+, LDi and all other variants use the same 22" + 14" blades.
Do these fit the Ertiga wiper arm?
Yes – the Ertiga uses a standard U-hook (J-hook) arm, and Prootto blades come with the matching adapter.
