This is the complete Maruti Suzuki Grand Vitara wiper blade size guide: verified sizes for every generation and model year, the variants each size fits, and how to replace the blades yourself in a couple of minutes.
Maruti Suzuki Grand Vitara wiper blade size – quick answer
- Maruti Suzuki Grand Vitara (2003–2015): 24" + 16" (600 mm + 400 mm)
- Maruti Suzuki Grand Vitara (2022–present): 24" + 17" (600 mm + 430 mm)
All sizes fit the standard U-hook (J-hook) wiper arm.
Maruti Suzuki Grand Vitara wiper blade size by generation
| Generation | Years | Driver side | Passenger side | |
|---|---|---|---|---|
| Grand Vitara (old, imported) | 2003–2015 (approx.) | 24" (600 mm) | 16" (400 mm) | Shop |
| Grand Vitara (new, hybrid) | Sep 2022–present | 24" (600 mm) | 17" (430 mm) | Shop |
Find your model year
- 24" + 16" – Grand Vitara (2003–2015): 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015
- 24" + 17" – Grand Vitara: 2022, 2023, 2024, 2025, 2026
Variants covered
Wiper size depends on the windscreen, not the trim, engine or fuel – every variant of a generation takes the same blades:
- Grand Vitara (2003–2015): 2.4 MT, 2.4 AT, 4WD
- Grand Vitara: Sigma, Delta, Zeta, Alpha, Strong Hybrid, AllGrip, CNG
How to replace Grand Vitara wiper blades
- Lift the wiper arm away from the windscreen until it locks upright.
- Press the release tab on the U-hook adapter and slide the old blade down off the hook.
- Slide the new blade onto the hook until it clicks into place.
- Lower the arm gently and repeat on the other side with the correct length.
- Test with washer fluid – the glass should be clear in one sweep.
When to replace
Every 6–12 months, or sooner if the blades streak, squeak, judder or leave unwiped patches – especially before the monsoon.
Buy Grand Vitara wiper blades
Prootto sells exact-fit sets of two in Conventional, Hybrid, Frameless and Carbon Aero:
- Maruti Suzuki Grand Vitara (2003–2015) wiper blades – 24" + 16"
- Maruti Suzuki Grand Vitara wiper blades – 24" + 17"
FAQs
What is the wiper blade size of the Maruti Suzuki Grand Vitara?
Grand Vitara (2003–2015): 24" + 16" (600 mm + 400 mm). Grand Vitara (2022–present): 24" + 17" (600 mm + 430 mm).
Is the wiper size the same for every Grand Vitara variant?
Yes. Within a generation, Sigma, Delta, Zeta, Alpha, Strong Hybrid and all other variants use the same 24" + 17" blades.
Do these fit the Grand Vitara wiper arm?
Yes – the Grand Vitara uses a standard U-hook (J-hook) arm, and Prootto blades come with the matching adapter.
