This is the complete Toyota Fortuner wiper blade size guide: verified sizes for every generation and model year, the variants each size fits, and how to replace the blades yourself in a couple of minutes.
Toyota Fortuner wiper blade size – quick answer
- Toyota Fortuner (2009–2016): 21" + 19" (530 mm + 480 mm)
- Toyota Fortuner (2016–present): 22" + 16" (550 mm + 400 mm)
- Toyota Fortuner Legender (2021–present): 22" + 16" (550 mm + 400 mm)
All sizes fit the standard U-hook (J-hook) wiper arm.
Toyota Fortuner wiper blade size by generation
| Generation | Years | Driver side | Passenger side | |
|---|---|---|---|---|
| Fortuner Gen 1 (incl. 2012 facelift) | 2009–2016 | 21" (530 mm) | 19" (480 mm) | Shop |
| Fortuner Gen 2 | 2016–2021 | 22" (550 mm) | 16" (400 mm) | Shop |
| Fortuner Gen 2 facelift | 2021–present | 22" (550 mm) | 16" (400 mm) | Shop |
| Legender | 2021–present | 22" (550 mm) | 16" (400 mm) | Shop |
Find your model year
- 21" + 19" – Fortuner (2009–2016): 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016
- 22" + 16" – Fortuner: 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
- 22" + 16" – Fortuner Legender: 2021, 2022, 2023, 2024, 2025, 2026
Variants covered
Wiper size depends on the windscreen, not the trim, engine or fuel – every variant of a generation takes the same blades:
- Fortuner (2009–2016): 4x2, 4x4, AT
- Fortuner: 4x2, 4x4, AT, GR-S
- Fortuner Legender: 4x2, 4x4
Which wiper blade type is best?
- Conventional (from ₹399 a set) – metal frame, dependable everyday wiping. Best value for city use.
- Hybrid (₹599) – frame inside an aerodynamic cover; firmer contact and a sleeker look.
- Frameless (₹699) – single curved beam for even pressure and quiet wiping at highway speed. Our pick for heavy monsoon rain.
- Carbon Aero (₹1,200) – premium frameless blade with a carbon-finish aero spoiler for the best high-speed performance.
Whichever type you choose, buy the exact size: a blade that is too long can hit the windscreen frame, and one that is too short leaves an unwiped band in your line of sight.
How to replace Fortuner wiper blades
- Lift the wiper arm away from the windscreen until it locks upright.
- Press the release tab on the U-hook adapter and slide the old blade down off the hook.
- Slide the new blade onto the hook until it clicks into place.
- Lower the arm gently and repeat on the other side with the correct length.
- Test with washer fluid – the glass should be clear in one sweep.
When to replace
Every 6–12 months, or sooner if the blades streak, squeak, judder or leave unwiped patches – especially before the monsoon.
Buy Fortuner wiper blades
Prootto sells exact-fit sets of two in Conventional, Hybrid, Frameless and Carbon Aero:
- Toyota Fortuner (2009–2016) wiper blades – 21" + 19"
- Toyota Fortuner wiper blades – 22" + 16"
- Toyota Fortuner Legender wiper blades – 22" + 16"
FAQs
What is the wiper blade size of the Toyota Fortuner?
Fortuner (2009–2016): 21" + 19" (530 mm + 480 mm). Fortuner (2016–present): 22" + 16" (550 mm + 400 mm). Fortuner Legender (2021–present): 22" + 16" (550 mm + 400 mm).
Is the wiper size the same for every Fortuner variant?
Yes. Within a generation, 4x2, 4x4 and all other variants use the same 22" + 16" blades.
Do these fit the Fortuner wiper arm?
Yes – the Fortuner uses a standard U-hook (J-hook) arm, and Prootto blades come with the matching adapter.
