This is the complete Toyota Innova / Innova Crysta wiper blade size guide: verified sizes for every generation and model year, the variants each size fits, and how to replace the blades yourself in a couple of minutes.
Toyota Innova / Innova Crysta wiper blade size – quick answer
- Toyota Innova (2005–2016): 24" + 16" (600 mm + 400 mm)
- Toyota Innova Crysta (2016–present): 26" + 16" (650 mm + 400 mm)
All sizes fit the standard U-hook (J-hook) wiper arm.
Toyota Innova / Innova Crysta wiper blade size by generation
| Generation | Years | Driver side | Passenger side | |
|---|---|---|---|---|
| Innova (incl. 2009 & 2012 facelifts) | 2005–2016 | 24" (600 mm) | 16" (400 mm) | Shop |
| Innova Crysta | 2016–2020 | 26" (650 mm) | 16" (400 mm) | Shop |
| Innova Crysta facelift | 2020–present | 26" (650 mm) | 16" (400 mm) | Shop |
Find your model year
- 24" + 16" – Innova: 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016
- 26" + 16" – Innova Crysta: 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Variants covered
Wiper size depends on the windscreen, not the trim, engine or fuel – every variant of a generation takes the same blades:
- Innova: E, G, GX, V, VX, ZX
- Innova Crysta: G, GX, VX, ZX
Which wiper blade type is best?
- Conventional (from ₹399 a set) – metal frame, dependable everyday wiping. Best value for city use.
- Hybrid (₹599) – frame inside an aerodynamic cover; firmer contact and a sleeker look.
- Frameless (₹699) – single curved beam for even pressure and quiet wiping at highway speed. Our pick for heavy monsoon rain.
- Carbon Aero (₹1,200) – premium frameless blade with a carbon-finish aero spoiler for the best high-speed performance.
Whichever type you choose, buy the exact size: a blade that is too long can hit the windscreen frame, and one that is too short leaves an unwiped band in your line of sight.
How to replace Innova / Innova Crysta wiper blades
- Lift the wiper arm away from the windscreen until it locks upright.
- Press the release tab on the U-hook adapter and slide the old blade down off the hook.
- Slide the new blade onto the hook until it clicks into place.
- Lower the arm gently and repeat on the other side with the correct length.
- Test with washer fluid – the glass should be clear in one sweep.
When to replace
Every 6–12 months, or sooner if the blades streak, squeak, judder or leave unwiped patches – especially before the monsoon.
Buy Innova / Innova Crysta wiper blades
Prootto sells exact-fit sets of two in Conventional, Hybrid, Frameless and Carbon Aero:
FAQs
What is the wiper blade size of the Toyota Innova / Innova Crysta?
Innova (2005–2016): 24" + 16" (600 mm + 400 mm). Innova Crysta (2016–present): 26" + 16" (650 mm + 400 mm).
Is the wiper size the same for every Innova / Innova Crysta variant?
Yes. Within a generation, G, GX, VX, ZX and all other variants use the same 26" + 16" blades.
Do these fit the Innova / Innova Crysta wiper arm?
Yes – the Innova / Innova Crysta uses a standard U-hook (J-hook) arm, and Prootto blades come with the matching adapter.
